Pump Model

• AL0918


Configuration

• Horizontal Triplex Piston


Number of Pistons

• 3


Stroke Length

• 2.25 Inches (57.2 mm)


Frame Load Rating

• 2800 lbs. (1,270 kg)


Pump Weight

• 200 lbs. (90.7 kg)


Direction of Rotation

• Top of Shaft away from head


Internal Gear Rotation

• 3.6:1


Intermittent Duty Speed Rating

• 890 RPM (Jackshaft)


Continuous Duty Speed Rating

• 750 RPM (Jackshaft)


Ball Valve Max Speed Rating

• 625 RPM


Minimum Speed

• 360 RPM


Mechanical Efficiency

• 85%


Lubrication System

• Splash, Gravity Return


Lube Oil Capacity

• 2.25 Quarts

Lube Oil Type

• SAE 30

Maximum Fluid Temperature

• 140F (250 Capability)

Minimum Fluid Temperature

• 0F (-20 Capability)


Standard Suction Size

• 1.50 Inch NPT (38.1 mm)


Standard Discharge Size

• 1.00 Inch NPT (25.4 mm)


Fluid End Material

• Cast Iron


Valve Type

• Disc Valve / Ball Valve


Hydraulic Motor Mount

• SAE C - 4 Bolt with 1.25”-14T
